Aluminium 60 Cell Solar Panels 360 Watt Monocrystalline Solar Panels

Name: Aluminium 60 Cell Solar Panels 360 Watt Monocrystalline Solar Panels
Brand: Hochiry
Price: 1 USD

China Aluminium 60 Cell Solar Panels 360 Watt Monocrystalline Solar Panels wholesale

Brand Name : Hochiry

Model Number : HCR360M-60

Certification : TUV

Place of Origin : CHINA

MOQ : 100PCS

Payment Terms : T/T, Western Union, MoneyGram

Delivery Time : 20-25 work days

Packaging Details : 27pcs/ per pallet 270pcs/ 1*20' container 648pcs/ 1*40' container

Product name : Monocrystalline Solar Panels

Solar cell : 9BB Mono 156.75*79.375 Cell

Number of cells : 60cells

Max. power : 320W 340W 360W

Solar Cells : Monocrystalline,Polycrystalline,Amorphous Silicon

Frame : Anodized Aluminium Alloy

Material : Monocrystalline Silicon

Warranty : 25 Years Output Power Guarantee

Panel Efficiency : High Efficiency

Glass : 3.2mm High Transmission Tempered Glass

Solar Panel Type : PERC, Half Cell, Bifacial

Contact Now

320 Watt 360 Watt 60 Cell Solar Panels Monocrystalline Solar Panels

Model Number:HCR360M-60
Weight:24kg
Size:2115*1052*40mm(Opt)
Junction Box:IP68 Rated
Solar cell: Monocrystalline, PERC,166mm(9BB)
TPT back sheet:White Backsheet
Connector:MC4 Compatible /MC4 EVO2/TS4*
Glass:3.2mm, High Transmission, AR Coated Heat

Half Cut Technology
Under the same shadow condition, power loss of half-cell solar panel is less than that of full cell solar panel.

Multi Busbar Technology
MBB technology improves efficiency of modules, offers a better aesthetic appearance.

PERC Technology
The PERC cell has a passivated rear side and a laser grooving process, which significantly improves the cell efficiency.

Products Description Miêu tả

Aluminium 60 Cell Solar Panels 360 Watt Monocrystalline Solar Panels

Electrical Parameters HCR320M-60 ~ HCR360M-60
Encapsulation	Class/Eva/Cell/Eva/Backsheet
Maximum Power Pmax (W)	300	310	320	330	340	350	360
Maximum Power Voltage (Vmp/V)	32.6	33.0	33.4	33.8	34.2	34.6	34.8
Maximum Power Current (Imp/A)	9.22	9.4	9.58	9.76	9.94	10.12	10.3
Open Circuit Voltage (Voc/V)	40.2	40.6	41	41.6	42.2	42.8	43.4
Short Circuit Current (Isc/A)	9.82	9.98	10.14	10.3	10.46	10.62	10.78
Cell Efficiency(%)	19.84	20.5	21.16	21.82	22.5	23.15	23.81
Module Efficiency (%)	17.98	18.58	19.18	19.78	20.38	20.98	21.58
Power Tolerance (W)	0 ~ +5W
Temperature Coefficient of Isc (αIsc)	+0.059%/℃
Temperature Coefficient of Voc (βVoc)	-0.330%/℃
Temperature Coefficient of Pmax (γPmp)	-0.410%/℃
STC	Irradiance 1000W/㎡, Cell Temperature 25℃ , Air Mass 1.5

Product Details

Glass by XINYI,SG CNBMAnti-reflective glass

22% Higher Efficiency Cell by  Tier 1 Brand

Frame by Tentop(Black/Silver Optional) 120N Tensile Strength Frame

Waterproof Labels Product by Waterproof Labels Sunway/OEM

Juction Boxes by TL, QC Solar Innovative Full-Glue-Filled IP68 Waterproofness

PV Connector by TL, QC Solar MC4 4mm Qualified cable

Our Factory

Product Packaging

Note: The Above packing information contained in this web is subject to change without notice. We will offer wooden box packing
 with extra material and labor costs if your order less than a pallet, we accept any customized packing as per your requests.

Project Case
